Title: ROV Jason 2 Sled
Author: Debbie Kelley
Category: Instruments
File Size: 125 kb
File Type: Image (JPG or GIF)
Date Catalogued: Tuesday, August 30, 2005

Drill sled mounted on Jason 2. In preparation for a dive, sled and explosives charges are mounted. The charges drive a cutter that will terminate the barrel if the drill becomes stuck in a hole. An A-frame shaped hydraulic lever arm in the front can be roated forward to allow a third touch point on the vehicle for stability and leveling of the drill.
